Top
SURFACE
Top is a miniaturized surface-mounted ceiling luminaire. Its compact design makes Top an ideal solution for installation in ceiling cavities and for projects where a discrete presence of the luminaire in the scene is desired. Formally Top presents itself as a design of pure lines and architectural aesthetics. In terms of lighting, Top offers a conical distribution with three available beam angles (flood, medium and spot). Its installation is extremely easy and safe, fixing it to the ceiling by means of a bayonet system that does not require the use of any tools.
Awards
-
Archiproducts Design Award Winner 2018
-
European Product Design Winner 2019
Top Mini
-
Luminous flux
480 / 610 lm / 500 / 640 lm / 515 / 655 lm
-
Lighting efficiency
86% / 89% / 92%
-
Power
4,5 / 6,5 W
-
Dimming
No Dim / DALI / Push / 1-10V
-
Color temperature
2700K / 3000K / 4000K
-
Sealing
IP20
-
Chromatic stability
MacAdam Step 2
-
Light beam angle
20° / 30° / 56°
-
Model
Ref.
Color
Source
Lum. flux
Power
Temp.
CRI
Beam angle
Efficiency
Dimming
Sealing
-
Reference:
A2960010NT
Color:Textured black
Light source:LED
Luminous flux:480 / 610 lm
Power:4,5 / 6,5 W
Colour temperature:2700K
CRI:CRI>90
Light beam angle:20°
Lighting efficiency:92%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960010WT
Color:Textured white
Light source:LED
Luminous flux:480 / 610 lm
Power:4,5 / 6,5 W
Colour temperature:2700K
CRI:CRI>90
Light beam angle:20°
Lighting efficiency:92%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960011NT
Color:Textured black
Light source:LED
Luminous flux:500 / 640 lm
Power:4,5 / 6,5 W
Colour temperature:3000K
CRI:CRI>90
Light beam angle:20°
Lighting efficiency:92%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960011WT
Color:Textured white
Light source:LED
Luminous flux:500 / 640 lm
Power:4,5 / 6,5 W
Colour temperature:3000K
CRI:CRI>90
Light beam angle:20°
Lighting efficiency:92%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960012NT
Color:Textured black
Light source:LED
Luminous flux:515 / 655 lm
Power:4,5 / 6,5 W
Colour temperature:4000K
CRI:CRI>90
Light beam angle:20°
Lighting efficiency:92%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960012WT
Color:Textured white
Light source:LED
Luminous flux:515 / 655 lm
Power:4,5 / 6,5 W
Colour temperature:4000K
CRI:CRI>90
Light beam angle:20°
Lighting efficiency:92%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960020NT
Color:Textured black
Light source:LED
Luminous flux:480 / 610 lm
Power:4,5 / 6,5 W
Colour temperature:2700K
CRI:CRI>90
Light beam angle:30°
Lighting efficiency:89%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960020WT
Color:Textured white
Light source:LED
Luminous flux:480 / 610 lm
Power:4,5 / 6,5 W
Colour temperature:2700K
CRI:CRI>90
Light beam angle:30°
Lighting efficiency:89%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960021NT
Color:Textured black
Light source:LED
Luminous flux:500 / 640 lm
Power:4,5 / 6,5 W
Colour temperature:3000K
CRI:CRI>90
Light beam angle:30°
Lighting efficiency:89%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960021WT
Color:Textured white
Light source:LED
Luminous flux:500 / 640 lm
Power:4,5 / 6,5 W
Colour temperature:3000K
CRI:CRI>90
Light beam angle:30°
Lighting efficiency:89%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960022NT
Color:Textured black
Light source:LED
Luminous flux:515 / 655 lm
Power:4,5 / 6,5 W
Colour temperature:4000K
CRI:CRI>90
Light beam angle:30°
Lighting efficiency:89%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960022WT
Color:Textured white
Light source:LED
Luminous flux:515 / 655 lm
Power:4,5 / 6,5 W
Colour temperature:4000K
CRI:CRI>90
Light beam angle:30°
Lighting efficiency:89%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960030NT
Color:Textured black
Light source:LED
Luminous flux:480 / 610 lm
Power:4,5 / 6,5 W
Colour temperature:2700K
CRI:CRI>90
Light beam angle:56°
Lighting efficiency:86%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960030WT
Color:Textured white
Light source:LED
Luminous flux:480 / 610 lm
Power:4,5 / 6,5 W
Colour temperature:2700K
CRI:CRI>90
Light beam angle:56°
Lighting efficiency:86%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960031NT
Color:Textured black
Light source:LED
Luminous flux:500 / 640 lm
Power:4,5 / 6,5 W
Colour temperature:3000K
CRI:CRI>90
Light beam angle:56°
Lighting efficiency:86%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960031WT
Color:Textured white
Light source:LED
Luminous flux:500 / 640 lm
Power:4,5 / 6,5 W
Colour temperature:3000K
CRI:CRI>90
Light beam angle:56°
Lighting efficiency:86%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960032NT
Color:Textured black
Light source:LED
Luminous flux:515 / 655 lm
Power:4,5 / 6,5 W
Colour temperature:4000K
CRI:CRI>90
Light beam angle:56°
Lighting efficiency:86%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
-
Reference:
A2960032WT
Color:Textured white
Light source:LED
Luminous flux:515 / 655 lm
Power:4,5 / 6,5 W
Colour temperature:4000K
CRI:CRI>90
Light beam angle:56°
Lighting efficiency:86%
Dimming:No Dim / DALI / Push / 1-10V
Sealing:IP20
